M12 Male Panel Mount, PCB Type, Front fastened, Y2-coding, Shielded
M12_2021 P346
Part No：MB12MBSY208ST-2
- Specification
- Application
- Certified
Connector series: M12
Gender: Male
Coding: Y2
Locking type: Fix screw
Mounting type: Front fastened
Part No.: MB12MBSY208ST-2
General information
Standard: IEC 61076-2-113 Ambient temperature: -40℃ ~ +80℃ (fixed installation)
-20℃ ~ +80℃ (flexible installation)Connector insert: PA+GF Connector contacts: Brass with gold plated Coupling nut/screw: Brass/Zinc with nickel plated Seal/O-ring: FKM Insulation resistance: ≥100MΩ Contact resistance: ≤10mΩ Shielding： Available IP rating: IP67 in locked condition
Electrical data & Mechanical data
Contacts Available
codingRated current Voltage Contacts
terminationA/C D/C 08 pins Y2 12A 50V 50V PCB
