Current Location： Home > Product > Waterproof UHF Connector

ProductsProducts

Waterproof UHF Connector

DB_2025 P572
Part No：UHF

Product Inquiry
  • Specification
  • Application
  • Certified

  • Connector series: UHF

  • Gender: Female

  • Locking type: Fix screw

  • Mounting type: Front fastened

  • Part No.: UHF


  • General information

    Ambient temperature: -30℃ ~ +85℃
    Connector insert: PTFE
    Connector contacts: Brass with gold plated
    Coupling nut/screw: PA+GF
    Seal/O-ring: Epoxy resin
    Insulation resistance: ≥100MΩ
    Contact resistance: ≤5mΩ
    Shielding： Available
    IP rating: IP67 in locked condition


    Electrical data & Mechanical data

    Contacts Rated current Voltage Contacts termination
    A/C D/C
    / 1A 250V 250V Solder
