- Specification
- Application
- Certified
Connector series: RJ45
Gender: Male
Locking type: Fix screw
Mounting type: Front mounting
Part No.: M12/RJ45-MDST
General information
Ambient temperature: -25℃ ~ +85℃ Connector insert: PA Connector contacts: Copper alloy Connector body: PA+GF oupling nut/screw: Brass with nickel plated Seal/O-ring: FKM Insulation resistance: ≥100MΩ Contact resistance: ≤30mΩ Shielding： Unavailable IP rating: M12/RJ45 male IP67 in locked condition
Electrical data & Mechanical data
Contacts Rated current Voltage Wire gauge/size Cable
jacketWire
insulationCable ending
& lengthA/C D/C AWG mm² 04 pins 1.5A 150V 150V 24 0.25 PVC PE Custom version
available
