- Specification
- Application
- Certified
Connector series: M12
Gender: Male&Female
Coding: A
Locking type: Fix screw
Mounting type: Straight
Part No.: MT-079~80
General information
Standard: IEC 61076-2-101 Ambient temperature: -25℃ ~ +90℃ Connector insert: PA/TPU Connector contacts: Brass with gold plated Coupling nut/screw: Brass with nickel plated Seal/O-ring: Epoxy resin/FKM Insulation resistance: ≥100MΩ Contact resistance: ≤5mΩ Shielding： Unavailable Mount thread: PG9 IP rating: IP67 in locked condition
Electrical data & Mechanical data
Contacts Available
codingPart No. Rated current Voltage A/C D/C 04 pins A MT-079 4A 250V 250V 05 pins A MT-080 4A 60V 60V
